Applications:
It is ideal used for cosmetic product 1 color screen printing. Such as cosmetic bottle, nail polish cap, cream jar, soft tube, deco mascara, lipstick cap. The design avoids the scratch on the part surface. The part shape can be round, conical, oval, and square.
The printing object can be made of plastic, metal, glass.
Features:
1. Manually put parts on the infeed conveyor and innovative outfeed conveyor design avoid the scratch on the surface of part.
2. Suitable for the objects that need positioning and no need positioning.
3. Servo motor control printing and unload, achieve high precision.
4. UV curing，LED curing and hot air drying device are optional.
5. Core parts are from German, USA and Japan to ensure the machine quality and stability of printing.
Specifications:
|
Printing speed |
2100-2400 Pieces/hour |
|
Part dimension |
Φ10-50mm, length 20-90mm |
|
Compressed air pressure |
6-8 Bar |
|
LPG |
1.5 Bar |
|
Machine size |
L 1100*W 1200*H 1900mm |
|
Power |
AC 380V, 3-Phase, 50Hz/60Hz, 10Kw（Conventional UV）, 5Kw(LED UV) |
