Applications:
Pad printer is widely applied in many industries including toys, plastic, electronic, glass, metal, electrical appliances, ceramics, die-casting products, optical, sporting goods, stationery, etc.
For example, rulers, pens, golf balls, ping-pong, eyes of doll, cap of bottle, watches, cameras, ceramic, pharmaceutical and medical equipment, rackets, tapes, electronic components, IC, CPU, DRAM, keyboard, mouse, cell phone shell, decorative signs, etc.
Features:
- Suitable for one color small size fast printing, widely apply in many industries including stationery, toys, plastic, gift, electrical appliances, electronic, etc.
- Microprocessor operation system, electro-pneumatic control;
- 125mm standard stroke, tabletop, ink basin and ink cup design;
- High printing speed, reach to 3600 cycles/hour;
- Independent adjustment of up and down, forward and rear stroke;
- Versatile X, Y printing pad adjustment;
- Ink well base with X, Y, Z adjustment, worktable X,Y adjustment;
- Heavy-duty construction with cabinet;
- Stable, durable working and fine workmanship;
- Foot pedal operation for single cycle;
- Installed safety guard and emergency stop button (optional);
- Complying with CE safety standards.
- Operation manual.
Specifications:
Model NO. | LP-125B-1 | LP-125C-1 |
Ink cystem | Ink basin | Ink cup |
Plate Size | 100x100mm | 200x100mm |
Ink cup size | ○ | ID82*OD90/ID53*OD60 |
Max. Printing Area | 80x80mm | Dia 80/60mm |
Printing Speed | 3000 cycles/hour | 3000 cycles/hour |
Working Stroke | 125 mm | 125mm |
Air Consumption | 5 bar | 5 bar |
Power | 110V/220V 50/60Hz 40W | |
Machine Dimension | 680x330x750 mm | |
Packing Dimension | 350x550x850 mm | |
Shipping Weight | 45 kg |
